Detailed Product Description
| Producing Efficiency: | 45m/min | Precision: | ±1mm |
|---|---|---|---|
| Label Max Width: | 190mm | Label Inner Diameter: | 76.2mm |
| Label Outer Diameter: | 330mm | Used: | Widely Used |
Alcoholic Beverage Round Bottles Sticker Labeling Machine Equipment
Product Characteristic
1 , The machine is applicable to label cylinder bottles for daily chemicals,beverages,pharmaceuticals etc.
2 , The machine adopts the special structure of air driving and labeling rollers with high labeling accuracy.
3 , The machine is particularly applicable to circular label for big round bottles, high repeat accuracy, without air bladder, with special design, no need the structure of separate bottle it makes the system easier, higher efficiency.
4 , The range of labels is extended because of hign-power servo motor. Solves the common problem of the insufficient strength.
5 , The machine adopts our company patent technology. The inaccurate labeling is eliminated largely because of the structure of three rollers capable of locating labeling position, automatically.
6 , It can be chosen to label one piece or two pieces, and it can label the washing hand liquid bottles in front and back at the same time.
7 , The advanced kind human interface system, on-line helping system,really human-machine communicating, it is easy to operate so the worker can operate the machine in several hours.
Technical Parameters
| Production speed | 45m/min |
| Labeling accuracy | ±1mm |
| Label max width | 190mm |
| Bottle diameter | 30-100mm |
| Label inner diameter | 76.2mm |
| Label outer diameter | Max330mm |
| Outline size | L2000×W700×1400mm |
| Air source | 4-6KG 30L/MIn |
| Using power | 220V 50HZ 1200W |
Application
1 , The machine is apply to the Daily Chemical and Food Industry.
2 , Labeling max width is 190mm(can be raised according to the require)
3 , Bottle diameter:30-100mm, Label inner diameter is 76.2mm, max outer diameter is 330mm.
4 , The air pressure pump of air source is 4-6KG, about 30L/MIn.
Advantages
1 , Most component are made by aluminum,cutting the weight and cutting the transportation fees.
2 , The production max speed is about 45m/min.Labeling accuracy is ±1mm.
3 ,Customized of the machine’s Using power,dimension,Weight.
Samples of client
Tag: pet bottle labeling machine, wrap around label applicator
