Little Round Bottle Sticker Labeling Machine For Pharmaceuticals Industry

Detailed Product Description

Type:	Little Round Bottle Sticker Labeling Machine	Material:	Aluminum/Stainless Steel
Application:	Pharmaceuticals Industry	Production Speed:	500pcs/min
Labeling Accuracy:	±0.5mm	Label Max Width:	130mm
Bottle Diameter:	10-30mm	Outline Size:	L2500×W1200×1600mm
Weight:	380KG	Usng Power:	220V 50HZ 1500W

Little Round Bottle Sticker Labeling Machine For Pharmaceuticals Industry

Specification

Production speed	500pcs/min
Labeling accuracy	±0.5mm
Label max width	130mm
Bottle diameter	10-30mm
Label inner diameter	76.2mm
Label outer diameter	330mm
Outline size	L2500×W1200×1600mm
Weight	380KG
Using power	220V 50HZ 1500W

Product Characteristic

1, Applications to ampoules bottle,vials bottle,oral liquid and other small round bottle labeling with high-speed precision

2, Special making vertical feeding,screw vertical to horizontal mechanism,horizontal labeling design,effectively solves the problem which various slender bottle can not keep consistent problems in feeding and labeling.

3, Inclineda type conveyor belt,settle the core tilt problem of ampoules bottle. The customer can choose stand feeding or horizontal feeding according to their own production line. Can choose the thermal transfer printer,inkjet or laser printer synchronization complete coding and labeling

4, Can choose the video detection device provides a variety of detection function,such as labeling detection,leak code detection function and code printing content detection,the unqualified products will be eliminated recovery

Application

1 , The machine is apply to the pharmaceutical industry,Labeling max width is 130mm.

2 , Bottles diameter is between 10-30mm,also label inner dameter is 76.2mm.

3 , Max diameter diameter is 330mm

Advantage

1 , Most component are made by aluminum,cutting the weight and cutting the transportation fees.

2 , The production max speed is about 500pcs/min.Labeling accuracy is ±0.5mm.

3 , The machine’s Using power,dimension,Weight are customized.

Bottles
