Poly Bag Flat Surface Label Applicator Machine

Detailed Product Description

Name:	Certification Self Adhesive Sticker Polybag Flat Surface Label Applicator Can Be Customized	Machine Size:	1600(L)×550(W)×1600(H)mm
Output Speed:	20-200pcs/min	Thickness Of Object:	20-120mm
Label Hight:	15-110mm	Power Supply:	220V 50/60HZ 0.75KW

certification self-adhesive sticker polybag flat surface label applicator Can be customized

Features

Operation	PLC control system makes labeling machine easy to operate
Material	Labeling machine's main body is made of SUS304 stainless steel
Configuration	Our labeling machines adopt well known Japanese, German, American, Korean or Taiwan brand parts
Flexibility	Client can choose to add printer and code machine; can choose to connect with conveyer or not.

Technical Parameters

Name	automatic envelope plastic flat surface label applicator
Labeling Speed	20-200pcs/min
Height of Object	30-200mm
Thickness of Object	20-120mm
Height of Label	15-110mm
Length of Label	25-300mm
Label Roller Inside Diameter	76mm
Label Roller Outside Diameter	300mm
Accuracy of Labeling	±1mm
Power Supply	220V 50/60HZ 0.75KW
Gas Consumption of Printer	5Kg/m2(if add coding machine)
Size of Labeling Machine	1600(L)×550(W)×1600(H)mm
Weight of Labeling Machine	150kg

Our Services

1. Offer you professional labeling solution according to your specific labeling requirements.

2. Supply you high quality labeling machine after placing order.

3. Try to make the delivery time as short to meet your needs.

4. Provide you lifelong free technical support after you receiving our machine.

What information should we supply to check the suitable model?

Pls send us picture of your container and label, as well as the container and label size.

Pls also tell us what kind of label you use, if possible. (For example, self-adhesive, could glue, hot glue, etc. whether the labels are in roll or pieces.)

Then, we'll let you check the suitable model.

Tag: flat label applicator, box labeling machine
